Thinner shells mean darker timbre and increased resonance

1 of 2 » View in gallery

• Related News
• Review

Based in County Durham, drum builder Andrew Street registered Liberty Drums as a limited company in 2006. The MPX is Liberty's latest, high-end, American maple shell pack drum kit, featuring fashionably shallow 'fast' toms.

Build

The MP (maple) X (extremely thin) kit is a five-shell pack with 10"x6" and 12"x6" shallow toms, together with 14"x12" and 16"x14" floor toms and a 22"x18" bass drum. The bass drum is undrilled and the small toms have lightweight aluminium Gauger RIMS mounts.

The most striking thing about this set is the thin North American maple shells. The toms are six ply and 3.9mm thick while the bass drum is eight ply and 5.3mm thick. This, Andrew says, is the thinnest Liberty can make whilst guaranteeing the shells won't distort: "Just the right thickness for outstanding resonance but enough integrity to be strong."

Bearing edges are a sharp 45 degrees and are cut and finished superbly. It's obvious great care has been lavished on these shells and they are blemish-free, the timber of high quality. Andrew currently uses his own design wooden moulds, but has begun converting to hydraulic, alloy moulds.

The bass drum hoops are also maple ply, finished in contrasting natural lacquer, and have sharp edges, which we found a bit surprising. Surprising because everything else has been done with such thought and we'd prefer these to be rounded off slightly.

The outside is satin mahogany (Mann's Brown Mahogany stain), one of six standard finishes. Unusually these days, the inside is finished in exactly the same way - another indication of Liberty's assiduousness. If you really want a different finish, Liberty can also do stain fades, or solid or stain high glosses.

The MPX certainly has a distinctive look. The lugs are off-set top and bottom, forming a diagonal pattern around the shells. This is actually necessitated on the small toms by the shallow 6" shell depths - the generic, rounded lugs themselves being quite bulky. But, for consistency, the pattern is carried through on the large toms and bass drum also.

Like most small new companies, Liberty relies on generic metalwork. This is no big deal except that you don't get the exclusivity of the big manufacturers. The bass drum spurs, tom tom legs and snare throw-off are all familiar, reliable designs. The toms have 2.3mm gauge steel hoops as standard, but Liberty can do a coloured powder coating if you so desire.

Each drum is finished off with a rather tasty, etched Liberty badge. The 14"x6" review snare drum was included as another example of what Liberty can offer. It's a contrasting design in Finnish birch ply with natural gloss satin lacquer. The shell is rather thicker at 7.5mm (15-ply, each ply 0.5mm thick) and Liberty also offers to make snare shells via stave or single-ply steam bent construction, in 13" or 14" diameters and a choice of depths.

This drum has 10 double-ended bridge lugs and die-cast rims rather than the standard triple-flanged.
